| Parameter |
Specification / Description |
| Chamber Inner Size |
1000 mm (W) × 1000 mm (D) × 1000 mm (H) |
| UUT Weight Capacity |
50 kg |
| Inner Construction Material |
18 SWG SS304 grade stainless steel |
| Insulation Thickness |
100 mm high-density, low K-factor bonded rock wool |
| Standard Compliance |
IEC 60529 (Talcum powder only), DIN 40050 IP5X & IP6X (vertical dust flow with optional under-pressure), IEC 60068-2-68 (vertical dust flow) |
| Alternative Standards |
SAE J575 and ISO 20653 |
| Dust Circulation Design |
Uniform floating dust simulation using free-flow dust circulation centrifugal blower, deep W-shaped hopper for dust collection & dispersion. Concentration: 2 kg per cubic meter of chamber volume maintained |
