Description
The outdoor solar module will endure the erosion of rain, fog, snow and sandstorm. To make sure that solar module will not wet leakage current accident and tolerate huge load pressure in such harsh conditions, we adopt wet leakage current to simulate the above weather conditions.
Features
- The tester complies with 10.15 of MQT 15 of IEC 61215-2, IEC 61646, and Test Specification MST17 of IEC 61730-2:2016.
- Equipped with mobile wheel, easily move the device to the required position, on arriving the required point you can set the testing equipment through fixing castor brake
Technical Specification
-
The max testing dimension is up to 1.8 m x 2.6 m.
-
Outer Dimensions of Test Stand:3000 x 2000 x 200mm or above (WxLxH)
-
Source Voltage range: 0 ̴ 2000VDC
-
Hipot Test Voltage: 0-10kVDC
-
Insulation Resistance voltage range:0 ̴ 1500V or above
-
Water Temperature Control: Maintained Through Water Chiller
-
Water Temperature Display: Digital Display
-
Safety Provision
